    Self-learning Remote Control
    Name：T3粉
    Model：T3粉

    Pre:  T1
    Next:  T99 PLUS

    • Features
    • Specification

    General specification

    frequency range  400-480MHz
    channel capacity 128
    Channel spacing 25.0kHz / 12.5kHz
    Frequency stability ±1.5ppm
    working temperature -20℃ ~ +60℃
    Antenna impedance 50Ω
    working voltage 3.7V
    Dimensions (L * w * h) 118×55×34mm
    Weight (with battery and antenna) 252g
    Battery 1500mAh (Lithium ion battery)

    Acceptance specification

    Receiving sensitivity 0.15μV / 0.18μV
    Adjacent channel selectivity 65dB / 55dB
    Intermodulation Rejection 55dB
    Spurious Response ≥60dB
    Signal to noise ratio 40dB / 35dB
    Rated audio output power ≥600mW
    Rated audio distortion ≤5%

    Launch specifications

    Transmitting power ≤5W
    modulation mode 16KΦF3E / 8KΦF3E
    Modulation limit ≤5kHz / ±2.5kHz
    FM distortion ≤5%
    residual FM -45dB / -35dB
    Adjacent channel power -65dB / -55dB
    Stray and harmonic ≤-36dBm
